Telephone Multi Pair Wire – PVC Insulated Communication Cable
Telephone Multi Pair Wire (TMP Series) is a premium communication cable manufactured with solid tinned electrolytic copper conductors, PVC insulated twisted pairs, and a durable PVC outer sheath. Available in 1 to 100 pair configurations, it is ideal for telephone wiring, EPABX systems, intercoms, tele-signalling, internet connectivity, and telecommunication equipment.
[yith_wcwl_add_to_wishlist]
- Description
- Reviews (0)
Description
Telephone Multi Pair Wire – PVC Insulated Communication Cable
Model: TMP Series
The Telephone Multi Pair Wire (TMP Series) from Metaplast Engineering LLP is a high-quality communication cable designed for dependable voice and data transmission in telecommunication and low-voltage networking systems. Manufactured using solid tinned electrolytic copper conductors, each conductor is insulated with premium PVC and twisted into individual pairs to minimize crosstalk and reduce static noise.
The paired conductors are arranged in concentric layers, wrapped with polyester or PVC tape, and protected by a durable PVC outer sheath for enhanced mechanical strength and long service life. Engineered for clear signal transmission and reliable communication, the cable is ideal for telephone exchanges, offices, hotels, intercom systems, and telecommunication networks.
Key Features
- Solid Tinned Electrolytic Copper Conductors
- Individually Twisted Pair Construction
- Low Crosstalk & Reduced Static Noise
- PVC Insulated Conductors
- Polyester/PVC Tape Binding
- Durable PVC Outer Sheath
- Excellent Signal Integrity
- Flexible & Easy Installation
- Available from 1 Pair to 100 Pair
- Suitable for OEM & Telecom Applications
Description
| Cat No | Conductor Size mm | Max. Conductor resistance Ohms/km | Insulation Thickness | No. of Pairs | Max. Overall Diameter | ||
|---|---|---|---|---|---|---|---|
| 0.5mm | 0.6mm | 0.7mm | |||||
| TMP-1(mm) | 0.5 | 92.2 0.2 | 1P | 3.5 | 3.5 | 4.3 | |
| TMP-2(mm) | 2P | 4.5 | 5.1 | 6.9 | |||
| TMP-3(mm) | 3P | 5.6 | 6.2 | 7.7 | |||
| TMP-4(mm) | 0.6 | 64 | 0.2 | 4P | 6.0 | 6.7 | 7.9 |
| TMP-5(mm) | 5P | 6.5 | 7.2 | 9.0 | |||
| TMP-6(mm) | 6P | 6.8 | 7.8 | 9.7 | |||
| TMP-10(mm) | 0.7 | 45.7 0.2810P | 9.0 | 10.0 | 10.4 | ||
| TMP-20(mm) | 20P | 11.5 | 13.0 | 14.0 | |||
| TMP-50(mm) | 50P | 16.2 | 8.3 | 21.0 | |||
| TMP-100(mm) | 100P | 22.8 | 23.8 | 30.0 | |||
Applications
- Telephone Networks
- EPABX & Telephone Exchanges
- Office Communication Systems
- Hotels & Commercial Buildings
- Residential Telephone Wiring
- Intercom Systems
- Tele-Signalling Systems
- Internet & Low-Speed Data Networks
- Industrial Communication Systems
- OEM Telecommunication Equipment
Metaplast Engineering LLP manufactures premium-quality communication cables, networking cables, instrumentation cables, power cords, molded plugs, and connectivity solutions engineered for superior signal transmission, durability, and long-term reliability across telecommunications, commercial, and industrial applications.
